  Spiral Wound Exhaust Pipe Gasket

Spiral Wound Exhaust Pipe Gasket

Item No.:ZD-G1202

Description:A spiral-wound gasket includes a plurality of tightly wound metal windings to form a core. The windings each have a Chervon cross-section, wherein V-notched undulations of each winding registers with an adjacent winding at said notches. The edges of the windings are welded to form a pre-assembled integral composite that is installed into a J-shaped outer wrap or cover. Finally, the cover is closed about the core so as to entirely cover and encapsulate the core. In a preferred form, both the core and outer cover are formed of stainless steel materials.Metal Spiral Wound Exhaust Pipe Gasket  For Motorcycle and Automobile Exhaust Pipe.It is used in motorcycle and automobile exhaust pipe system for sealing.There is "W" shape or "V" shape workable.And it's convenient to install or replace.

The Material:Usually,we use SSS316 or SS304 for higher temperature and rusted exhaust pipe system.But if there is no corrosion,the SS201,SS202 or tin-plated metal hoop are also workable.And the filler can be graphte(marked as FG),asbestos,non-asbestos,mica or ceramic tape.They are for different exhaust system.

Related Talble for Consult:

media    material

asbestos

graphite

non-asbestos

Ceramic

Mica

Water-type media

600℃,CL 2500

550℃,CL 1500

350℃,CL 1500

800℃, CL 1500

700℃,CL 1500

oil-type media

500℃,CL 1500

550℃,CL 600

350℃,CL 600

-

-

gas-type media

400℃,CL 600

550℃,CL 400

350℃,CL 400

-

-

The main style of spiral wound gasket:

1.Tinplate with white asbestos/non-asbestos/graphite

2.SUS304 with asbestos/non-asbestos/graphite

3.SS201 with red asbestos/non-asbestos/graphite

Special material can be produced as request
